ราคา 114,900.00 บาท
ค่าจัดส่งทั่วไทย
ประกัน 1 ปี
ปรึกษาด้านเทคนิก
Our Pro iDSD is for all music lovers, looking for their stairway to heaven.
Features :
Sample rates: |
PCM up to 768kHz DSD up to 49.152MHz (DSD 1024) DXD and double-speed DXD (2xDXD) |
Inputs: |
USB (required for DSD, DXD and sample rates above 192KHz) AES3 (XLR – single link) S/PDIF (coaxial/optical combo) BNC multifunction (S/PDIF in or sync input) |
Outputs: |
Balanced XLR at 4.6V (+15.5dBu – HiFi) or 10V (+22dBu – Pro) Single-Ended RCA at 2.3V (HiFi) or 5V (Pro) Headphones 6.3mm & SE 3.5mm Jack at 0.55V/2.1V/5V Headphones BAL 2.5mm/4.4mm Jack at 1.13V/4.6V/10V Headphones out 1,500mW RMS X 2 @ 64 ohm, 4,000mW max. 2 X @ 16 Ohm |
Headphone Output Impedance: |
Single-Ended (S-BAL): < 1 Ω Balanced: < 2 Ω |
Volume control: |
Balanced (6-gang) Alps potentiometer, motorised with IR remote control XLR/RCA outputs can be selected as fixed level or adjusted 6.3mm headphone jack is always adjusted |
Other Functions: | Various digital and analogue filters can be selected for DSD and PCM up to 384KHz |
PCM Filters: |
Bitperfect 44.1 – 192kHz, always used for 352.8 – 768kHz Bitperfect + 44.1 – 96kHz Gibbs Transient Optimised 44.1 – 384kHz Apodising 44.1 – 384kHz Transient Aligned 44.1 – 384kHz |
DSD filters: | fixed 3rd order analogue filter @ 80kHz with correction for DSD’s -6dB gain |
Gain (headphone section): | user-selectable: 0dB, 9dB and 18dB |
Dynamic range: | 119dBA (solid-state, PCM, -60dBFS) |
Output power |
Pro iDSD 4.4mm socket. (16 Ω, balanced/single-ended): >4200mW /1>1,575mW
Pro iDSD 2.5mm socket. (16 Ω, balanced/single-ended): >4000mW /1>1,500mW |
Output voltage | (600Ω, balanced/single-ended): >11.2V / >5.6V |
Input voltage (Pro iDSD): | DC 9V/6.7A – 18V/3.35A |
Input voltage (iPower+): | AC 85 – 265V, 50/60Hz |
Power consumption: | < 22W idle, 50W max. |
Dimensions: |
220 (w) x 213 (d) x 63(h) mm
8.7″ x 8.4″ x 2.5″ |
Weight: | 1980g (4.37 Ibs) |
