8-channel HD Video Production Switcher with 28-channel Audio Mixing, Color Display Screen, 3G SDI, HDMI, USB 3.0, LAN, and Included Software
หมายเลขสินค้า : V-80HD
ราคา 118,000.00 บาท
-
ตรวจสอบก่อน! ว่ามีสินค้าหรือไม่
-
*กรุณาโทรเช็คสต็อคสินค้าก่อนสั่ง 061-409-7760
เลือกจำนวน :
เลือกสี : Black
-
ฟรี!
ประกัน 1 ปี
-
ฟรี!
ปรึกษาด้านเทคนิก
แชร์ไปยัง :
8-channel HD Video Production Switcher with 28-channel Audio Mixing, Color Display Screen, 3G SDI, HDMI, USB 3.0, LAN, and Included Software
Compact and powerful, the V-80HD covers professional video production needs for in-person events, livestreaming, studio productions, and other applications. The all-in-one design is easy to carry and set up, while flexible I/O features support 3G SDI, HDMI, USB 3.0, and LAN (RTMP/SRT) connections. The V-80HD also includes multi-channel audio mixing and effects, integrated control for PTZ cameras, and remote operation with video monitoring via dedicated control apps. And with the companion Graphics Presenter software, you can easily enhance productions with impressive titles, motion graphics, and more.
Features
- 8-channel all-in-one video switcher for streaming, studio productions, live events, and house of worship applications
- Enormous control array offers a 5-layer video effects engine, downstream keying and composition, automation, sequencing, macros, and intelligent scene memories
- Large color display screen offers monitoring and streamlined navigation
- Integrated PTZ controlling with effortless brand and protocol fluidity
- 32-slot still store function permits screen capturing and sharing of BMP, JPEG, and PNG images on the spot
- 28-channel expansive audio mixer boasts output buses for effects and processing in an instant
- 8-pad function assignment for instantaneous customized recalling
- 4 x 3G SDI inputs with frame rate converters, 4 x 1080p HDMI inputs with dual input 4K downscaling and thru-put returning, 2 x SDI outputs, 3 x HDMI outputs, thru outputting, USB-C, and LAN (RTMP/SRT)
- 10 assignable buses, XLR I/O, stereo audio I/O and tally support for wired and wireless cameras
- Bluetooth, USB, RS-232, and wireless LAN (Wi-Fi) connectivity permits versatile digital usage for iPads, macOS, and Windows users with the V-80HD App
- Included Graphics Presenter software bundles titles, motion graphics, and more exciting visual effects to enhance your production
Multiple Video Inputs
The V-80HD features versatile input connectivity with HDMI for common A/V devices and SDI for long cable runs and high-end cameras. Eight total channels are available, enabling seamless switching for up to four HDMI and four SDI input sources. Two 4K HDMI inputs are equipped with downscalers and the ability to send parallel connections to gaming consoles at eSports events. Additionally, an SRT input can be assigned to a cross-point button together with an SDI and HDMI input.
Versatile Video Outputs and Flexible Routing
With its multiple assignable outputs—including two SDI and three HDMI video outputs, a USB-C streaming output, and LAN (RTMP/SRT)—the V-80HD puts a high-end video matrix at your command. Each output can be assigned to 10 buses, allowing you to feed program displays, auxiliary monitors, multi-view producer displays, and online audiences all at once.
Powerful Video Effects Engine
The V-80HD is filled with tools to elevate presentations with impressive video effects and graphics. The onboard effects engine features five composition layers that include a split-screen effect, two PinP windows with key composition, and one DSK with fill/key composite support. It’s simple to create common layouts, such as a business presentation with an individual speaker, image slides, and a title on a background. PinP and DSK layers can be managed individually on the Program, Sub-Program, and two Aux outputs, providing flexibility for any production need.
Professional Graphics Made Easy
The Graphics Presenter software for Windows allows you to create stunning titles and graphics without the need for expensive third-party graphic presentation solutions. Setup with the V-80HD is quick and straightforward, requiring only a single HDMI connection to send fill and key signals from the computer to the switcher.
Graphics Presenter offers an intuitive workflow with a wide selection of ready-to-edit templates, including animated title text, sports scores, motion graphics, and more. The software and templates are available free of charge, and additional content is periodically provided for download on Roland Cloud.
Plug-and-Play Streaming
The V-80HD uses the same connection technology as webcams, providing a plug-and-play streaming experience. Simply connect the USB-C output to a computer or smartphone and start streaming with Zoom, Microsoft Teams, or any platform that can use a webcam as its source. LAN connectivity is also supported, allowing you to stream directly to YouTube, Facebook Live, Twitch, or any RTMP platform without a computer.
Secure AV Transmission with SRT
The V-80HD supports SRT (Secure Reliable Transport), an open-source standard for AVoIP that provides secure encrypted audio and video transmission over IP networks. It also offers future-proof connectivity within installed system configurations. SRT allows you to seamlessly extend your V-80HD production capabilities via LAN or an internet connection. Access camera images from remote locations and switch them along with local HDMI and SDI sources. And send a dedicated SRT video output to an external destination, such as another building at the production location.
SDXC Card Recording
With the V-80HD’s onboard recorder, you can easily capture an event to an SDXC card and provide your client with an H.264 MP4 video file* for their editing and distribution needs. Stereo WAV audio can also be recorded independently for podcasts and other audio-driven media. It’s even possible to capture still images to internal memory from any video output bus and save them to the card for later use.
PTZ Camera Support
Robotic PTZ (pan-tilt-zoom) cameras greatly expand production capabilities, offering extended coverage with studio-grade broadcast quality. And thanks to their small size, they can be placed in discreet locations where larger cameras aren’t practical.
The V-80HD includes built-in control support for select Canon, JVC, Panasonic, Sony, PTZOptics, Avonic, and VISCA-compatible PTZ LAN cameras. Mix and match different brands and operate up to eight PTZ cameras simultaneously. The V-80HD Remote iPad App is an ideal companion for PTZ operation, providing remote camera controls and video monitoring from the tablet.
Rapid Workflow with Scenes and Macros
Storing and recalling custom looks can be accomplished with just a few button presses on the V-80HD. The 32 scene memories and powerful effects engine work together to provide seamless scene changes, including synchronizing the transition of all composition layers at the program output. The 100 macros go even deeper, allowing you to build and fire off complex action lists that include switching, DSK on/off, audio mixing adjustments, PTZ camera movements, and much more.
Our free remote control software for macOS, Windows, and iPad further enhances this workflow, providing a large graphical interface for setting up and previewing actions before you take them live.
Sequencing Magic
The V-80HD’s sequencer makes scenes and macros even more powerful, allowing a single operator to execute perfectly timed cues with ease. You can record up to 1000 steps, and each step can include both scenes and macros. Streamline your productions by setting up cues ahead of time in the sequence list and triggering them in order using the Next button on the panel.
Professional Audio Mixing and Effects
The V-80HD features 28 channels of audio mixing plus a wide selection of processing tools, I/O routing options, and automation features. Enhance sounds with ready-to-use effects, including high-quality vocal processing and a useful Loudness Auto Gain Control function to manage levels while streaming. With the onboard Audio Player, it’s simple to integrate dedicated music and sound effects into every production. Three output buses are available, ready to support complex routing needs for streaming events and studio recording configurations.
Customizable Control Pads
Eight user-assignable pads give you quick control of many V-80HD functions. The pads are organized into eight banks, providing direct access to 64 different operations. Call up scenes, macros, and sequencer steps, trigger audio and video clips, start/stop streams, and more. It’s even possible to control functions in the Graphics Presenter software when the host computer is connected to the V-80HD via USB.
Specifications
Processing
Switching Type : Pushbutton, Software, T-Bar
Color Processing : 8-Bit 4:2:2
Audio Processing : 48 kHz / 16-Bit
Input
Video Inputs :
- 4x HDMI
- 4x BNC
Input Video Format :
- HDMI
- UHD 4K at 23.98/24/25/29.97/30/50/59.94/60 fps
- 1080p at 23.98/24/25/29.97/30/60 fps
- 1080i at 50/59.94 fps
- WUXGA (1920 x 1200) at 60 fps
- UXGA (1600 x 1200) at 60 fps
- SXGA+ (1400 x 1050) at 60 fps
- FWXGA (1366 x 768) at 60 fps
- SXVGA (1280 x 1024) at 60 fps
- WXGA (1280 x 800) at 60 fps
- XGA (1024 x 768) at 60 fps
- SVGA (800 x 600) at 60 fps
- VGA (640 x 480) at 60 fps
- 720p at 50/59.94 fps
- 576i / 625 lines at 50 fps
- 576p at 50 fps
- 480i / 525 lines at 59.94 fps
- 480p at 59.94 fps
SDI :
- 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps
- 1080i at 50/59.94/60 fps
- 720p at 50/59.94 fps
Audio Inputs :
- 2x Combo XLR-1/4" TRS Female
- 1x 2RCA Female
Input Audio Format : Analog
Embedded Audio Input :
- HDMI
- SDI
Output
Video Outputs :
- 3x HDMI
- 2x BNC
Output Video Format :
- HDMI
- 1080p at 23.98/24/25/29.97/30/50/59.94/60 fps
- 1080i at 50/59.94/60 fps
- 720p at 50/59.94/60 fps
Audio Outputs :
- 2x XLR 3-Pin
- 1x 1/4" TRS Stereo
Output Audio Format : Analog
Embedded Audio Output :
- HDMI
- SDI
- USB-C
Connectivity
Other I/O
- 1x USB-C
- 1x USB-A
- 2x 1/4" TRS Control
- 1x DB-25 GPI, Tally
- 1x DE-9/DB-9 RS-232
- 1x RJ45 LAN
Video Standard Compliance : SMPTE 292M/425M-A/425M-B
HDCP Support : Yes
HDR Support : Yes
Display
Display Size : 4.3"
Screen Resolution : 480 x 272
Hardware
OS Compatibility :
- macOS
- Windows
Mobile App Compatible :
- Yes: iOS Only
- App Name: V-80HD Remote
Wi-Fi : No
Bluetooth : 5.0
Power
Power I/O : 1x Barrel Input
Power Consumption :
Power Supply: 24 VAC at 2.1 A
Device: 51 W
Environmental
Operating Temperature : 32 to 104°F / 0 to 40°C
General
Dimensions : 15.6 x 10 x 4.1" / 396 x 254 x 103 mm
Weight : 7.7 lb / 3.5 kg
